Our range of Hollow cylinders provide high force for both push and pull applications. Simplicity in design and high quality material selection makes our hollow cylinders suitable for many years of safe and reliable operation.
Metric Units
Switch to Imperial Units
General Spec
Measurement
Stroke with spring
19mm
Stroke without spring
60mm
Effective area
34.36cm²
Swept vol. with spring
54.97cm³
Swept vol. without spring
206.2cm³
Max Working Pressure
275-Bar
General Spec
Measurement
Stroke with spring
0.748in
Stroke without spring
2.362in
Effective area
5.3in²
Swept vol. with spring
3.34in³
Swept vol. without spring
12.6in³
Max Working Pressure
4000-PSI
